SGM808B.pdf? Operating Voltage Range: 0.95V to 10V
? High Accuracy Detection: ±1.5% at TJ = +25℃
? Low Power Consumption: 1μA (TYP) at VCC = 3.5V
? Detection Voltage Range: 1.5V to 6V (0.1VIncrements)
? Hysteresis Characteristics: 5% (TYP)
? N-Channel Open-Drain Output
? Available in Green SC70-4 (R),
SOT-23-5 andSOT-89-3 Packages
? Quiescent Current of 0.5 μA Typical
? High Accuracy Undervoltage Threshold of 2.0%
? Wide Operating Voltage Range of 0.8 V to 10 V
? Complementary or Open Drain Reset Output
? Active Low or Active High Reset Output
? Specified Over the ?40°C to +125°C
Temperature Range(Except for Voltage
Options from 0.9 to 1.1 V)
? NCV Prefix for Automotive and Other
Applications Requiring
Unique Site and Control Change
Requirements; AEC?Q100
Qualified and PPAP Capable
? These Devices are Pb?Free and
are RoHS Compliant
