SGM431.pdf? Reference Voltage Tolerance at +25℃:
SGM431: 1% (Standard Grade)
SGM431B: 0.5% (B Grade)
? Adjustable Output Voltage: VREF to 36V
? High Stability under Capacitive Load
? Typical Temperature Drift: 5mV
? Low Output Noise
? Typical Output Impedance: 0.1Ω
? Sink-Current Capability: 1mA to 100mA
? Operating Junction Temperature Range:-40℃ to +125℃
? The SGM431 is available in Green SOIC-8, SOT-23,
SOT-89-3, SOT-23-5 and SC70-6 Packages
? The SGM431B is available in Green SOIC-8,
SOT-23,SOT-89-3 and SOT-23-5 Packages
? Low-Voltage Operation/Wide Adjust Range
(1.24 V/30 V)
? 0.5% Initial Tolerance (LMV431B)
? Temperature Compensated for Industrial
Temperature Range (39 PPM/°C for the LMV431AI)
? Low Operation Current (55 μA)
? Low Output Impedance (0.25 ?)
? Fast Turn-On Response
? Low Cost
