SGM41600YG.pdf? Efficiency Optimized Switched-
Capacitor Architecture
Up to 6A Output Current
3.3V to 11.5V Input Voltage Range
200kHz to 1.5MHz Switching Frequency Setting
Up to 97% Voltage Divider Mode Efficiency
(when VBAT = 4V, IBAT = 3A)
? Comprehensive Integrated Protection Features
External OVP Control and Regulation
Input Over-Voltage Protection (BUS_OVP)
Input Short-Circuit Protection (BUS_SC)
Input Over-Current Protection (IBUS_OCP)
Input Under-Current Protection (IBUS_UCP)
Battery Over-Voltage Protection (BAT_OVP)
Output Short-Circuit Protection (VOUT_SC)
Battery Over-Current Protection (IBAT_OCP)
CFLY Short-Circuit Protection (CFLY_SC)
Converter Over-Current Protection (CONV_OCP)
Die Over-Temperature Protection (TDIE_OTP)
? 5-Channel 12-Bit (Effective) ADC Converter
VBUS, IBUS, VBAT, IBAT, TDIE Monitoring
