SCT52240.pdf? Wide Supply Voltage Range: 4.5V - 24V
? 4A Peak Source Current and 4A Peak Sink
Current
? Stackable Output for Higher Driving Capability
? Negative Input Voltage Capability: Down to -5V
? TTL Compatible Input Logic Threshold
? Propagation Delay: 13ns
? Typical Rising and Falling Times: 8ns
? Typical Delay Matching: 1ns
? Low Quiescent Current: 55uA
? Output Low When Input Floating
? Independent Enable Logic for Each Channel
? Thermal Shutdown Protection: 170°C
? Available in SOP-8 and eMSOP-8 Package
? Industry-Standard Pin Out
?Two Independent Gate-Drive Channels
? 5-A Peak Source and Sink-Drive Current
? Independent-Enable Function for Each Output
? TTL and CMOS Compatible Logic Threshold
Independent of Supply Voltage
? Hysteretic-Logic Thresholds for High Noise Immunity
? Ability to Handle Negative Voltages (-5 V) at Inputs
? Inputs and Enable Pin-Voltage Levels Not Restricted
by VDD Pin Bias Supply Voltage
? 4.5 to 18-V Single-Supply Range
? Outputs Held Low During VDD-UVLO, (ensures glitch
-free operation at power-up and power-down)
? Fast Propagation Delays (13-ns typical)
? Fast Rise and Fall Times (7-ns and 6-ns typical)
? 1-ns Typical Delay Matching Between 2-Channels
? Two Outputs are Paralleled for Higher Drive Current
? Outputs Held in LOW When Inputs Floating
? SOIC-8, MSOP-8 PowerPADTM Package Options
? Operating Temperature Range of –40°C to 140°C
