ACP2825.pdf? Input Voltage Range: 2.5V to 6V
? Output Current: 1.2A
? Adjustable Output with 0.6V Reference Voltage
? Automatic PFM Mode at Light Load
? Low Dropout 100% Duty Operation
? 1.5MHz Programmable Frequency
? Maximum 65μA Quiescent Current
? Internal Soft Start Function
? Excellent Line and Load Transient Response
? Short Circuit Protection
? Input Over Voltage Protection
? Under Voltage Lockout Protection
? 2.5V to 5.5V Input Voltage Range, with 6.5V
Transient Input Capability
? 70μA Low Quiescent Current
? Low RDS(ON) for Internal Switches (Top/Bottom)
260m? /170m?
? High Switching Frequency 1.5MHz Minimizes
the External Components
? Internal Soft-start Limits the Inrush Current
? 100% Dropout Operation
? Reliable Short Circuit Protection
? Output Auto Discharge Function
? RoHS Compliant and Halogen Free
